Wire Suspension System EWFS

The most universal M8 anchoring solution for suspended installations
Wire Suspension System EWFS
Product overview

Available in 2mm diameter cable and a variable length of 3 or 5 meters, this product has a M8 bolt in one of the cable ends to be screwed in a compatible CELO accessory (SAP M8, BTS6 H M8, etc.). The height can be easily adjusted through a wire gripper, offering greater flexibility.

Show more
Download documents
List of references
Filters
Length [m]
3
5
Close
Reference
d
J
9203M8EWFS
9205M8EWFS
Diameter [mm]
d
J
2
2
Length [m]
d
J
3
5
Allowable load [kg]
d
J
56
56
Packaging units
d
J
10
10
Packaging type.
d
J
Box
Box
A
t
2 / 2 references
Applications
  • Cable trays
  • Lighting system ceilings
  • Ventilation pipes
  • Industrial HVAC
Base materials
Suitable materials
Sandwich panel
Sandwich panel
Concrete
Concrete
Precast prestressed hollow core slabs
Precast prestressed hollow core slabs
Other related products
How to install
STEP 1: Drill a hole to the ceiling and fix the eyebolt. Use a compatible accessory and a M8 security nut if needed.
STEP 2: Use the open end and the gripper to hold the application.
STEP 3: Tighten the cable to adjust the aplication.
STEP 4: Leave enough room for some adjustments up to 60º
STEP 5: Cut the excess cable leaving a minimum of 5 cm of extra cable.
