Nailing Conduit Metal Clip PFT

For fast installation of conduits with nailers.
Product Image Metal Nailing Conduit Clip PFT
Product Image Nailing Metal Conduit Clip PFT
Mounting image PFT 4
Product overview

​​​​​​The nailing conduit metal clip PFT is the most suitable fixings system for installing cables, wires, fire alarm cables, (electrical) cables, flexible and rigid tubes, and heating pipes. Its R90 certificate ensures 90 minutes of integrity, meaning that wiring systems will not prematurely collapse in the event of a fire.

Show more
List of references
Reference
d
J
95PFT
96PFT
97PFT
98PFT
910PFT
912PFT
914PFT
916PFT
918PFT
920PFT
922PFT
925PFT
928PFT
932PFT
940PFT
950PFT
Diameter [mm]
d
J
4.5
6
6.5
7.5
9.5
11.5
13.5
15.5
17.5
19.5
21.5
24.5
27.5
31.5
39.5
49.5
Length [mm]
d
J
24
26
26.5
27.5
29.5
31.5
33.5
34.5
36.5
38.5
40.5
43.5
46.5
50.5
58.5
68.5
Height [mm]
d
J
3.8
5.5
6
7
9
11.5
13.5
15
17
18.5
20.5
23.5
26.5
30.5
38.5
48.5
Width [mm]
d
J
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
Material
d
J
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Steel
Coating
d
J
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
White zinc plated
Packaging units
d
J
100
100
100
100
100
100
100
100
100
100
100
100
100
100
50
50
Packaging type.
d
J
Box
Box
Box
Box
Box
Box
Box
Box
Box
Box
Box
Box
Box
Box
Box
Box
A
t
16 / 16 references
Applications
  • Alarm cable
  • Telecommunications cable
  • Signal cable
  • PVC pipes
  • Flexible and rigid plastic insulating pipes
  • Heating pipes
Further specifications

Key features:

  • Easy and quick installation on the ceiling thanks to the clip in the nailer nose, installation with only one hand
Base materials
eta
Suitable materials with approvals
Concrete
Concrete
Other suitable materials
Steel beam/purlin
Steel beam/purlin
Concrete block
Concrete block
Solid brick
Solid brick
Wood
Wood
