Setscrew flange beam clamp CMV M6

Multifunctional for threaded rods, cable ties, M6-screws etc.
CMV M6 Multi-Function Flange Beam Clamp
Packaging photo of box containing 50 pieces of CMV M6 ZnAl, side view
Packaging photo of the back side of the CELO box 13NE-9
Packaging photo of box containing 50 pieces of CMV M6 ZnAl, front view with label
Product overview

The CMV CNBOP fire approved flange beam clip is a fast and stable solution for fixings cables and pipes to metal beams with a flange width up to 16mm. Thanks to the quick assembly without drilling or welding simply by tightening the screw, the CMV beam clip helps you save time during installtion.

Show more
Download documents
View videos
List of references
Reference
d
J
96CMV
Flange thickness [mm]
d
J
< 16mm
Clearance hole [mm]
d
J
6.3
Clearance hole 2 [mm]
d
J
10.7
Thread
d
J
M6
Internal thread
d
J
M6
Torque
d
J
3
Material
d
J
Carbon spring steel
Packaging units
d
J
50
Packaging type.
d
J
Box
A
t
1 / 1 references
Applications
  • Suspended structure
  • Lighting
  • Signage
  • Cable installation
Base materials
Suitable materials
Steel beam/purlin
Steel beam/purlin
Other related products
How to install
Step 1
Step 2
Step 3
Step 4
Watch the video
Useful tips
When tightening the screw, it is intentionally offset and will not screw in straight, to achieve greater resistance.

Do you have any questions about this product?

Request more info
